Mặt bích tiêu chuẩn ANSI CLASS 600
HYUPSHIN FLANGES
1. Standard: ANSI B16.5, ASME B16.5
2. Type: Plate Flange, SOP Flange (Raised Face)
3. Pressure: Class 600
4. Size: 1/2" - 24", larger Sizes available on request
5. Raw Material: Carbon Steel: ASTM A105, A350
6. Process: Forged or Stamped
7. ASTM raw material specification
|
ANSI/ASME/ASA B16.5 600lb/sq.in. Flange Plate RF
|
|||||||||
|
ø
|
D
|
b
|
g
|
m
|
J
|
k
|
Holes
|
l
|
Kg.
|
|
1/2"
|
95,2
|
14,3
|
34,9
|
38,1
|
22,3
|
66,7
|
4
|
15,9
|
0,800
|
|
3/4"
|
117,5
|
15,9
|
42,9
|
47,6
|
27,7
|
82,5
|
4
|
19,0
|
1,400
|
|
1"
|
123,8
|
17,5
|
50,8
|
54,0
|
34,5
|
88,9
|
4
|
19,0
|
1,600
|
|
1 1/4"
|
133,3
|
20,6
|
63,5
|
63,5
|
43,2
|
98,4
|
4
|
19,0
|
2,100
|
|
1 1/2"
|
155,6
|
22,2
|
73,0
|
69,8
|
49,5
|
114,3
|
4
|
22,2
|
3,100
|
|
2"
|
165,1
|
25,4
|
92,1
|
84,1
|
62,0
|
127,0
|
8
|
19,0
|
3,700
|
|
2 1/2"
|
190,5
|
28,6
|
104,8
|
100,0
|
74,7
|
149,2
|
8
|
22,2
|
5,400
|
|
3"
|
209,5
|
31,7
|
127,0
|
117,5
|
90,7
|
168,3
|
8
|
22,2
|
7,300
|
|
3 1/2"
|
228,6
|
34,9
|
139,7
|
133,3
|
103,4
|
184,1
|
8
|
25,4
|
8,900
|
|
4"
|
273,0
|
38,1
|
157,2
|
152,4
|
116,1
|
215,9
|
8
|
25,4
|
11,800
|
|
5"
|
330,2
|
44,4
|
185,7
|
188,9
|
143,8
|
266,7
|
8
|
28,6
|
24,500
|
|
6"
|
355,6
|
47,6
|
215,9
|
222,2
|
170,7
|
292,1
|
12
|
28,6
|
29,500
|
|
8"
|
419,1
|
55,6
|
269,9
|
273,0
|
221,5
|
349,2
|
12
|
31,7
|
43,000
|
|
10"
|
508,0
|
63,5
|
323,8
|
342,8
|
276,3
|
431,8
|
16
|
34,9
|
70,000
|
|
12"
|
558,8
|
66,7
|
381,0
|
400,0
|
327,1
|
488,9
|
20
|
34,9
|
86,000
|
|
14"
|
603,2
|
69,8
|
412,7
|
431,8
|
359,1
|
527,0
|
20
|
38,1
|
100,000
|
|
16"
|
685,8
|
76,2
|
469,9
|
495,3
|
410,5
|
603,2
|
20
|
41,3
|
142,000
|
|
18"
|
742,9
|
82,5
|
533,4
|
546,1
|
461,8
|
654,0
|
20
|
44,4
|
175,000
|
|
20"
|
812,8
|
88,9
|
584,2
|
609,6
|
513,1
|
723,9
|
24
|
44,4
|
232,000
|
|
22"
|
869,9
|
95,2
|
641,2
|
666,7
|
564,4
|
777,9
|
24
|
47,6
|
292,000
|
|
24"
|
939,8
|
101,6
|
692,1
|
717,5
|
615,9
|
838,2
|
24
|
50,8
|
330,000
|
NOTE:
1. Class 600 flanges except Lap Joint will be furnished with 0.25 (6.35mm) raised face, which is not included in ‘Thickness’ (C) and ‘Length through Hub’ (Y1), (Y3).
2. For Slip-on, Threaded, Socket Welding and Lap Joint Flanges, the hubs can be shaped either vertical from base to top or tapered within the limits of 7 degrees.
3. Blind Flanges may be made with the same hub as that used for Slip-on Flanges or without hub.
4. The gasket surface and backside (bearing surface for bolting) are made parallel within 1 degree. To accomplish parallelism, spot facing is carried out according to MSS SP-9, without reducing thickness (C).
5. Dimensions of sizes 1/2 through 3 1/2 are the same as for Class 400 Flanges.
6. Depth of Socket (D) is covered by ANSI B 16.5 only in sizes through 3 inch, over 3 inch is at the manufacturer’s option.
